Name: PP Yarn String Wound Filter Cartridge Making Machine/ Production Line
Brand: Wuxi AJMS Filter Machinery Co.,Ltd.
SKU: AJMS1803
Price: 3,150.00 USD
Availability: InStock

Home Products 10"-100" PP String Wound Filter Cartridge Machine

PP Yarn String Wound Filter Cartridge Making Machine/ Production Line

Product Details:

Place of Origin:	China
Brand Name:	AJMS
Certification:	CE, ISO
Model Number:	AJMS1803

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	USD2300 - USD4000 per set
Packaging Details:	wooden case.
Delivery Time:	8 working days
Payment Terms:	L/C, T/T
Supply Ability:	1000pcs per month

Contact Now

Detailed Product Description

Product Name:	PP Yarn Sting Wound Filter Making Machine	Size:	10"-100" Just As Your Request
Inside Diameter:	Min 28mm	Outside Diameter:	Above 200mm Or As Your Request
Power:	430W	Motor Power:	180W/spindle, 250W/spindle
Motor Speed:	2800r/min	Winding Frame Material:	Polypropylene Or Stainless Steel, Etc.
Output:	95-120pcs	Single Spindle Panel Size:	(WxH) 390x308mm

PP Yarn String Wound Filter Cartridge Making Machine/ Production Line

All types of Machine

1.Single Head:

10’’ single head

20’’ single head

30’’ single head

40’’ single head

5’’,50’’,60’’,70’’,80’’...

100’’

2.Double Head:

10’’&10’’ double head

10’’&20’’ double head

30’’&40’’ double head

20’’&30’’ double head

40’’&40’’,10’’&30’’,

20’’ & 40’’....

Specifications of machines

Specification
1	type		power	Output(piece/hour)			mark
2	10inch		180W	50-60
3	20inch		250W	45-55
4	30inch		370W	25-30
5	40inch		370W	20-25
6	10inch&10inch		360W	100-120
7	10inch&20inch		430W	95-115
10&20 machine dimension :(LWH) :12006001250mm
30&40 machine dimension :(LWH) :18006001250mm

After packing size
Machine type		After packing size(LWH mm)			Net weight (KG)	Gross weight (KG)
Single
10inch		10506501400			50	80
20inch		12006001400			80	100
30inch		15006501400			100	120
50inch		21506501400			220	260
60inch		23006501400			220	300
70inch		26006501400			150	180
Double
10&10 inch		10506501400			80	100
10&20 inch		12006501400			110	150
20&30 inch		15006501400			180	200
30&40 inch		18506501400			220	260
40&40 inch		18006501250			250	280

Machine application:

PP String Wound Filter Cartridge Machine is mainly used in the fields of water purification, Beverage, foodstuff, chemical, greases, pharmacies, electronics, environmental protection etc,

it’s a dedicated machine for the winding of different yarns. This machine features novel design, high speed, low noise, high productivity, and good yarn forming ability. When the yarn full

buzzer alarms, the machine will stop automatically. This machine has many advantage as such as easy operation; convenient and pick yarn change , low energy consumption.

PP Yarn String Wound Filter Cartridge Making Machine/ Production Line
